« Previous On the bottom of the potentiometer, the wire is hot-glued in place: green for ground, and yellow and red on opposite ends of the slider tracks. Next »

The underside of the potentiometer, showing wires glued to the three terminals.


Credit: Image by MIT OpenCourseWare.
